Engine

Model

Rated power

179/2200 kW/r/min

Push and pull

Maximum pushing force

400 kN

Maximum push-pull speed

28 m/min

Rotate

Torque

14000 N.m

Maximum speed

104 r/min

Mud pump

Maximum flow

450 L/min

Maximum pressure

8 MPa

Drill pipe

83*3 mm*m

Truck mounted crane

Lifting weight

/ t

Lifting moment

/ t.m

Max. penetration angle

23

Max. back expansion diameter

900mm

Quality

11.5t

Overall dimension

7080*2450*2450mm
