KEY SPECS
Operating weight: 66,000 kg
Bucket capacity: 4 m3
Engine power: 566 kW/1900 rpm
Configuration selling point
High-power engine, customized large
displacement main pump, Weichai + Linde super powerful golden combination +
fully electronic control system.
Ease of maintenance and operation comfort
The machine is equipped with a 10.1-inch
capacitive touchscreen, featuring a full-fitting IPS screen with wide viewing
angles and high brightness, ensuring excellent visibility even under sunlight.
The machine also provides a spacious maintenance area, allowing for easy access
during inspections and maintenance.
Adaptability to diverse working conditions
It can be configured with a range of working
devices such as rock buckets, breaker hammers, ultra-powerful booms, rippers,
and a variety of buckets to meet different working condition requirements.
PARAMETER
|
Parameter
|
SE680LCW
|
|
Operating
weight(kg)
|
66000
|
|
Engine
power(kW/rpm)
|
566/1900
|
|
Bucket
capacity(m)
|
4
|
|
External
dimensions(mm)
|
12245*3735*4750
|
|
Bucket
rod digging force(kN)
|
350
|
|
Bucket
digging force(kN)
|
420
|
|
Rotating
speed(r/min)
|
0-7.2
|
|
Travel
speed(km/h)
|
3.2/4.7
|
|
Maximum
digging height(mm)
|
10855
|
|
Maximum
digging distance(mm)
|
11520
|
|
Maximum
digging depth(mm)
|
7040
|
|
Emissions
(Indicated as per international standards)
|
Eu
stage IIIA
|
