An asphalt mixing plant is a comprehensive equipment set designed for batch production, capable of producing asphalt mixtures, modified asphalt mixtures, and color asphalt mixtures. It finds extensive use in highway construction, grade highways, municipal roads, airports, bridges, ports, as well as water conservancy and hydropower projects.

The asphalt mixing plant primarily consists of various key components, including the batching system, drying system, combustion system, hot lifting system, vibrating screen, hot storage bin, weighing and mixing system, bitumen supply system, filler supply system, dust collection system, finished product bin, and control system.

Key Features:

• Modular Design: Our asphalt mixing equipment is designed with modularity in mind, offering a compact structure. The mixing pot boasts a large capacity, and its blades and lining boards are made of durable nickel hard alloy, ensuring a service life of over 100,000 batches. The inclusion of a unique drop correction function and bitumen secondary weighing function guarantees precise measurements and bitumen-aggregate ratio accuracy.

• High Efficiency: The asphalt mixing plant's modular design facilitates easy installation, maintenance, relocation, and transportation, with a productivity range spanning from 80t/h to 400 t/h.

• High Stability: Controlled by an industrial PC/PLC system, the equipment operates automatically, semi-automatically, or manually. It offers features such as formula input, automatic difference correction, dynamic tracking of bitumen-aggregate ratios, automatic fault diagnosis, alarms, and real-time printing.

• Environmental Protection: Equipped with an inertia + pulse cleaning bag filter, the plant adheres to stringent environmental standards. The fly ash is recyclable, and both noise and emissions comply with national industry standards. The equipment is suitable for use in both urban and field construction.

• Energy Saving: The asphalt mixing plant boasts low total installation power, with fuel consumption less than 6.5 kgs per ton of asphalt mixture, making it a cost-effective choice for customers.
