Engine

Model

Cummins 4BT3.9-C100

Rated power

74/2200 kW/r/min

Push and pull

Maximum pushing force

120 kN

Maximum push-pull speed

37 m/min

Rotate

torque

3000N.m

Maximum speed

220 r/min

Mud pump

Maximum flow

100 L/min

Maximum pressure

4 MPa

Drill pipe

52*18 mm*m

Truck mounted crane

Lifting weight

/ t

Lifting moment

/ t.m

Max. penetration angle

18

Max. back expansion diameter

400mm

Quality

4.5t

Overall dimension

4500*1680*2170mm
