Engine

Model

Rated power

221/2100 kW/r/min

Push and pull

Maximum pushing force

970 kN

Maximum push-pull speed

50 m/min

Rotate

Torque

33000 N.m

Maximum speed

120 r/min

Mud pump

Maximum flow

600 L/min

Maximum pressure

10 MPa

Drill pipe

106*6 mm*m

Truck mounted crane

Lifting weight

2 t

Lifting moment

4 t.m

Max. penetration angle

20

Max. back expansion diameter

1000mm

Quality

16.2t

Overall dimension

10650*2450*2600mm
