Bore diameter(mm)

115-800

Bore depth(m)

1200

Walk speed(km/h)

0-2.5

For rock(F)

6--20

Air pressure(Mpa)

1.05-4.0

Air consumption(m/min)

16-50

Once promotion(mm)

6000

Skid max angle()

90

Maximum height from the ground(mm)

320

Rotation Speed(r/min)

0-100

Rotation torque(NM)

18000

Lifting power(T)

50

Climb ability()

15

DimensionL*W*H)(mm)

8750*2200*3000

Weight(T)

18.6

Note: The Companys products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation.
