When space is tight, the neat compact design with zero tail swing gets you to work.

Control is everything. Load sensing hydraulics deliver precise and smooth operation for excellent grading performance.

The fuel efficient, low noise and low emission Stage V certified KUBOTA D902 engine gives the operator the power to perform.

Operating Weight: 1750/1850 kg

Rated power: 11.8 kW

Bucket Capacity:0.045 m

Product Features

:

Specifications

Operating weight: 1750 kg

Engine power: 11.8 kW @ 2,300 rpm

Bucket capacity: 0.045 m

Maximum travel speed (High): 4.0 km/h

Maximum travel speed (Low): 2.2 km/h

Maximum swing speed: 9.5 rpm

Arm breakout force: 9 kN

Bucket breakout force: 16 kN

Shipping length: 2410 mm

Shipping width: 980 mm

Shipping height: 2410 mm

Track shoe width (std): 230 mm

Boom: 1685 mm

Arm: 1070 mm

Digging reach: 3910 mm

Digging reach on ground: 3840 mm

Digging depth: 2255 mm

Vertical wall digging depth: 1780 mm

Cutting height: 3420 mm

Dumping height: 2400 mm

Minimum front swing radius: 645 mm

Model: Kubota D902

Emission: EU Stage V / Tier 4F

System maximum flow: 44 L/min ( 11.6 gal/min)
