KEY SPECS
Operating Mass: 4750 kg
Compaction width: 1370 mm
Static linear load: 13 kg/cm
Feature & Benefit
Big fuel savings with ECO!
Any Dynapac product equipped with a Stage IV engine, is not only
compliant with the latest emission stage but is also contributing to
great fuel cost savings.
Any Dynapac product equipped with a Stage IV engine, is not only
compliant with the latest emission stage but is also contributing to
great fuel cost savings.
| Masses |
| Operating mass (incl. ROPS) |
4750 kg |
| Operating mass (incl. Cab) |
4900 kg |
| Module mass (front/rear) |
2000 kg/ 2750 kg |
| Max. operating mass |
5350 kg |
| Traction |
| Speed range (Dual/TC/AS) |
0 - 6 km/h |
| Tyre size (10 ply) |
12.5-20 |
| Max. theoretical gradeability |
52 % |
| Vertical oscillation |
9 |
| Number of pads |
72 |
| Pad area |
53 cm2 |
| Pad height |
76 mm |
| Compaction |
| Static linear load |
13 kg/cm |
| Nominal amplitude |
1.5 mm |
| Vibration frequency |
35 Hz |
| Centrifugal force |
89 kN |
| Frequency |
ECO: 30 Hz |
| Engine |
| Emission stage |
|
| Manufacturer/Model |
Kubota V 3307 CR-TE4 (Stage IIIB/Tier4) |
| Type |
Water cooled turbo Diesel |
| Rated power, SAE J1995 |
55 kW (75 hp) @ 2.200 rpm |
| Fuel tank capacity |
117 l |
| Alternative Engine |
| Manufacturer/Model |
Kubota V 3307 CR-TE5 (Stage V) |
| Type |
Water cooled turbo Diesel |
| Rated power, SAE J1995 |
55 kW (75 hp ) @ 2.200 rpm |
| Fuel tank capacity |
117 l |
| Hydraulic system |
| Driving |
Axial piston pump with variable displacement.
Axial piston motor with constant displacement.
Axial piston motor with constant displacement. |
| Vibration |
Gear pump/ motor with constant displacement. |
| Steering |
Gear pump with constant displacem. |
| Service brake |
Hydrostatic in forward and reverse lever. |
Parking/
Emergency brake |
Failsafe multidisc brake in rear axle and front drum motor. |
| Noise emissions |
| 2000/14/EG, LwA | dB(A) |
|---|
