KEY SPECS
Operating weight: 15000 kg
Bucket capacity: 0.65 m3
Engine power: 89 kW/2200 rpm
Configuration selling point
The machine is equipped with the internationally renowned
engine known for its great power reserve and robust power. Its high-end
negative-flow system ensures stability and reliability, making it the golden
configuration among machines of the same tonnage. With high system pressure and
a large flow rate, the machine delivers quick response and efficient operation.
Ease of maintenance and operation comfort
The engine hood is supported by dual gas cylinders and opens
backward, featuring lightweight opening and wide opening angle to facilitate
easy maintenance. Fuel filter elements, oil filter elements, and pilot filter
elements are all centrally located, allowing for all maintenance and
replacements to be completed at the same location
Adaptability to diverse working conditions
With its heavy weight, the machine demonstrates good
stability. It is equipped with hydraulic cylinders with a large diameter to
provide large digging force, and features the industrys largest bucket
capacity. The machine offers multiple preset working modes, enabling its
versatile application in diverse working conditions, including excavation,
leveling, crushing, and lifting operations.
PARAMETER
|
Parameter
|
SE150
|
|
Operating weight(kg)
|
15000
|
|
Engine power(kW/rpm)
|
89/2200
|
|
Bucket capacity(m)
|
0.65
|
|
External dimensions(mm)
|
7860*2645*2855
|
|
Bucket rod digging force(kN)
|
70
|
|
Bucket digging force(kN)
|
105
|
|
Rotating speed(r/min)
|
11.3
|
|
Travel speed(km/h)
|
3.25/5.2
|
|
Maximum digging height(mm)
|
8670
|
|
Maximum digging distance(mm)
|
8325
|
|
Maximum digging depth(mm)
|
5490
|
|
Emissions (Indicated as per international standards)
|
Eu stage IIIA
|
