KEY SPECS
Operating weight: 32,000 kg
Bucket capacity: 1.3/1.5m3
Engine power: 199 kW/2200 rpm
Configuration selling point
The Weichai WP7 engine, customized and calibrated, is
utilized in the machine to ensure higher efficiency and lower fuel consumption.
The new-generation main pump incorporates leading technology, resulting in
improved reliability.
Ease of maintenance and operation comfort
The machine is equipped with a 10.1-inch touchscreen,
enabling improved human-machine interaction and convenient operation. It also
provides a spacious maintenance area, allowing for easy access during
inspections and maintenance.
Adaptability to diverse working conditions
The machine offers an easy combination with booms, bucket
rods, buckets, and other attachments of varying specifications. It provides
multiple working modes and gear settings to meet the requirements of diverse
working conditions.
PARAMETER
|
Parameter
|
SE305LCW
|
|
Operating weight(kg)
|
32000
|
|
Engine power(kW/rpm)
|
199/2000
|
|
Bucket capacity(m)
|
1.3/1.5
|
|
External dimensions(mm)
|
10880*3200*3850
|
|
Bucket rod digging force(kN)
|
155
|
|
Bucket digging force(kN)
|
210
|
|
Rotating speed(r/min)
|
0-10
|
|
Travel speed(km/h)
|
3.3/5.5
|
|
Maximum digging height(mm)
|
10030
|
|
Maximum digging distance(mm)
|
10580
|
|
Maximum digging depth(mm)
|
6760
|
|
Emissions (Indicated as per international standards)
|
Eu stage IIIA
|
