KEY SPECS
Operating weight: 13500 kg
Bucket capacity: 0.6 m3
Engine power: 129 kW/2200 rpm
Configuration selling point
The Weichai engine guarantees superior performance, while
the Rexroth travel motor and ZF transmission ensure exceptional reliability and
durability.
Ease of maintenance and operation comfort
Engine oil filters and fuel filters are centrally located
for integrated system maintenance. Hydraulic system filter elements and engine
filter elements are located in the same compartment, providing one-door access
and a centralized layout that saves time and effort!
Adaptability to diverse working conditions
The machine comes standard with a hydraulic lock for the
bulldozer blade. It features a large-capacity brake accumulator that enhances
braking safety by providing a greater reserve. It incorporates advanced
adjustment technology specifically designed for crawler excavators and is
equipped with a self-developed controller that perfectly matches its control
logic.
PARAMETER
|
Parameter
|
SW150
|
|
Operating weight(kg)
|
13500
|
|
Engine power(kW/rpm)
|
129/2200
|
|
Bucket capacity(m)
|
0.6
|
|
External dimensions(mm)
|
7960*2528*3220
|
|
Bucket rod digging force(kN)
|
72
|
|
Bucket digging force(kN)
|
102.5
|
|
Rotating speed(r/min)
|
0-11.3
|
|
Travel speed(km/h)
|
10/37
|
|
Maximum digging height(mm)
|
8755
|
|
Maximum digging distance(mm)
|
7950
|
|
Maximum digging depth(mm)
|
4715
|
|
Emissions (Indicated as per international standards)
|
Eu stage IIIA
|
