| Bucket capacity | m | 0.95 |
| Operating weight | kg | 21300 |
| Dimension parameters | Wheel spacing | mm | 3465 |
| Total track length | mm | 4220 |
| Ground clearance of platform | mm | 1060 |
| Platform min. slewing radius | mm | 2750 |
| Boarding width | mm | 2710 |
| Gauge | mm | 2200 |
| Chassis width | mm | 2800 |
| Track width | mm | 600 |
| Chassis clearance from the ground | mm | 470 |
| Total height | mm | 2965 |
| The height of the boom during transport | mm | 3045 |
| Transport length | mm | 9590 |
Working
range | Max. digging height | mm | 9740 |
| Max. discharging height | mm | 6980 |
| Max. digging depth | mm | 6690 |
| 8 feet horizontal digging depth | mm | 6500 |
| Max. vertical digging depth | mm | 6040 |
| Max. digging radius | mm | 9950 |
| Max. digging reach at ground level | mm | 9785 |
| Min. slewing radius | mm | 3530 |
| Engine | Brand |
| ISUZU |
| Rated output power | kW/rpm | 110/2100 |
| Max. digging force (bucket rod) | kN | 110 |
| Max. digging force (bucket) | kN | 154 |
| Driving speed (high/low) | km/h | 4.9/3.1 |
| Slewing speed | rpm | 11.8 |
| Ground specific pressure | kpa | 43.2 |
