| Type of cab | Cabin/canopy |
| Bucket capacity | m3 | 0.04 |
| Bucket width, std. | mm | 380 |
| Machine weight | kg | 1940/1840 |
| Dimensions | Overall length | mm | 3820 |
| Overall height | mm | 2370 |
| Overall width | mm | 990 |
| Ground clearance | mm | 482 |
| Engine | Brand | Yanmar |
| Model | 3TNV80F-SSSU |
| Displacement | L | 1.267 |
| Output | kW/rpm | 13.4/2200 |
| Working ranges | Max cutting height | mm | 3770 |
| Max loading height | mm | 2720 |
| Max digging depth | mm | 2380 |
| Max digging reach | mm | 4040 |
| Boom swing angle(Left/Right) | | 75/50 |
| Front swing radius | mm | 1565 |
| Tail swing radius | mm | 1120 |
| Max digging force (Arm) | kN | 9.83 |
| Max digging force (Bucket | kN | 22.7 |
| Track | Type |
| Rubber track |
| Rubber shoe width | mm | 230 |
| Undercarriage | Track length | mm | 1555 |
| Length to center of rollers | mm | 1210 |
| Length to center of track | mm | 760/1130 |
| Traveling speed(High/Low) | km/h | 3.5/2 |
| Gradeability | deg | 30 |
| Swing speed | rpm | 10 |
| Ground pressure | kpa | 30 |
| Dozer size | Width | mm | 990/1360 |
| Height | mm | 267 |
| Lifting capacity (Height/Depth) | mm | 295/360 |
Hydraulic
pumps | Type |
| 2 variable plunger pumps, 1 Gear pump |
| Flow rate | L/min | 2*21+15 |
| Hydraulic pressure | Mpa | 22.5+18 |
| Swing motor |
| Plunger motor |
| Travel motor |
| 2-speed plunger motor |
| Fuel tank capacity | L | 23 |
| Hydraulic oil tank capacity | L | 35 |
