| Bucket capacity | m | 0.4~0.52 |
| Operating weight | kg | 9100 |
| Dimension parameters | Wheel spacing | mm | 2560 |
| Total track length | mm | 3225 |
| Ground clearance of platform | mm | 845 |
| Platform min. slewing radius | mm | 1870 |
| Chassis width | mm | 2320 |
| Track width | mm | 450 |
| Chassis clearance from the ground | mm | 370 |
| Track height | mm | 700 |
| Total length | mm | 6470 |
| Total height | mm | 2660 |
| Total width | mm | 2250 |
Working
range | Max. digging height | mm | 7515 |
| Max. discharging height | mm | 5315 |
| Max. digging depth | mm | 4375 |
| Max. vertical digging depth | mm | 3930 |
| Max. digging radius | mm | 6950 |
| Max. digging reach at ground level | mm | 6800 |
| Min. slewing radius | mm | 2250 |
| Engine | Brand |
| KUBOTA |
| Rated output power | kW/rpm | 60.7/2200 |
| Max. digging force (bucket rod) | kN | 43 |
| Max. digging force (bucket) | kN | 64.5 |
| Driving speed (high/low) | km/h | 4.5/2.7 |
| Slewing speed | rpm | 9 |
| Ground specific pressure | kpa | 36.8 |
