| Bucket capacity | m | 0.6~0.7 |
| Operating weight | kg | 14800 |
| Dimension parameters | Wheel spacing | mm | 3000 |
| Total track length | mm | 3735 |
| Ground clearance of platform | mm | 915 |
| Platform min. slewing radius | mm | 2350 |
| Chassis width | mm | 2600 |
| Track width | mm | 600 |
| Chassis clearance from the ground | mm | 410 |
| Track height | mm | 825 |
| Total length | mm | 7815 |
| Total height | mm | 2825 |
| Total width | mm | 2520 |
Working
range | Max. digging height | mm | 8630 |
| Max. discharging height | mm | 6130 |
| Max. digging depth | mm | 5640 |
| Max. vertical digging depth | mm | 4540 |
| Max. digging radius | mm | 8355 |
| Max. digging reach at ground level | mm | 8230 |
| Min. slewing radius | mm | 2510 |
| Engine | Brand |
| ISUZU |
| Rated output power | kW/rpm | 84/2200 |
| Max. digging force (bucket rod) | kN | 72.5 |
| Max. digging force (bucket) | kN | 98 |
| Driving speed (high/low) | km/h | 5.4/3.3 |
| Slewing speed | rpm | 11.1 |
| Ground specific pressure | kpa | 36 |
