Perform finish grading using only arm input

Your operators can finish grade quickly and accurately with a bucket angle hold control that automatically holds the bucket angle to the design surface during arm operation, enabling operators to perform finish grading using only arm input.

Auto tilt bucket control

Auto tilt bucket control assists the operator in aligning the bucket parallel with the slope, so that finish grading can be accomplished without having to align the machine with the target surface.

Adjusts to the operators experience level

A fully integrated grade assist automatically traces the target surface to minimize over digging. A built-in facing angle compass ensures the machine is aligned with the target surface.

Auto stop control

To help eliminate potential damage during boom or bucket operation, the machine automatically stops when the bucket edge reaches the design surface.

Minimum distance control

IMC controls the bucket by automatically selecting the point closest to the target surface, which minimizes operator input while providing higher accuracy and grading confidence.

Critical precision for utility applications

For utility customers looking for the utmost precision, the excavator allows your operator to input structure, invert elevations of pipe runs and automatically calculates fall of pipe.

Powerful, advanced engine

Your fleet can be environmentally friendly without sacrificing power. Excavators with IMC 1.0 are equipment with a Tier 4 Final certified Komatsu SAA6D107E-3 engine, which features an integrated diesel particulate filter, hydraulically actuated Komatsu variable geometry turbocharger and selective Ccatalytic reduction system.

Stroke sensing hydraulic cylinder

Stroke sensing hydraulic cylinders provide real-time position that is immediately displayed to the operator. This is an improvement over conventional aftermarket machine guidance (indicate only) systems with tilt sensors that require time to stabilize.

Robust undercarriage

A large counterweight and robust undercarriage components help provide outstanding stability.
